Characteristics of IFB PLATFORM COUNTING SCALE
- Special platform for the industrial sector.
- Stainless steel plate.
- Backlit LCD display (silver-indicator cable 1.5 m).
- Table stand including wall bracket for indicator, as standard.
- External calibration.
- Parts counting function.
- RS 232 data output.
- Dynamic weighing at the touch of a button: Creates a stable average value.
- Weighing with tolerance limits (check-weighing) by means of luminous and acoustic signals. Facilitates the process of rationing, dosing or sorting.
- Sum of weight values.
Max. capacity (Kg) |
Plate (mm) |
Capacity (Kg) |
Reading (g) |
Min load. (g) |
15 |
400x300x128 |
|
|
40 g |
30 |
400x300x128 |
|
|
100 g |
60 |
400x300x128 |
|
|
200 g |
60 |
500x400x137 |
|
|
200 g |
150 |
650x500x137 |
|
|
400 g |
150 |
650x500x142 |
|
|
400 g |
300 |
650x500x142 |
|
|
1000 g |
How to interpret the table reading in capacity and reading:
For example in the first case that puts capacity (kg)
and reading (g)
This means that up to 6 kg. the reading is 2 g. in 2 g. and from 6 kg. the reading is 5 g. in 5 g.
- Capacity 30 kg. 400 X 300 X 128
- 60 kg capacity 400 X 300 X 128
- 60 kg capacity 500 X 400 X 137
- Capacity 150 kg 500 X 400 X 137
- Capacity 150 kg 650 X 500 X 142
- 300 kg capacity 650 X 500 X 142
